The Fairchild Industrial Controls Division designs and manufactures the most complete line of precision pneumatic and electro-pneumatic control devices available. Fairchild's control devices include:
• Fairchild Pneumatic Pressure Regulators
• Filter Regulators
• M/P converters
• Fairchild Pressure Booster
• Fairchild Pneumatic relays
• Current to Pressure Transducers
• Voltage to Pressure Transducers
• Fairchild Pressure to Current Transducers
High Precision Pressure Regulators The Fairchild Models 10 and 81 are ideal for general precision pressure regulator applications, while the compact Models 30 and 80 offer high precision in a small package. The Model 100 high flow regulator, the 1000 no bleed pressure regulator, the 4000A no bleed high flow regulator and the Model 4100A Low Pressure regulator also offer high precision control Back Pressure Regulators
Back Pressure Regulators work well where applications require high precision control of back pressure or relief pressures. The Model 10BP offers high precision, as does the compact Model 30BP. In addition, the Model 50BP Polymer, Model 66BP Stainless Steel, and Model 4000ABP high flow back pressure regulators are designed by Fairchild for tough applications.
Miniature Pressure Regulators
Fairchild Model 70 miniature regulator offers high precision in a tiny package. The new Model 72 High Performance Miniature Regulator features an improved design for even better performance, while the Model 50 Polymer regulator excels in lightweight, medical or tough applications.
Fairchild vacuum regulators cover all applications from full vacuum in the Model 17 Vacuum Regulator and Model 18 Vacuum Relief Regulator to those in low pressure and lighter vacuum, handled by the Model 16 Vacuum Regulator and the Model 1600 High Flow Vacuum Regulator. Filter/Service Pressure Regulators
High flow and good filtration are critically important and the Fairchild Model 63 and slightly wider Model 65 filter service pressure regulators offer world class performance on both counts. For a service regulator, the Model 64 standard and the Model 66 Stainless Service Pressure Regulators will exceed your expectations. Specialty Pressure Regulators
Accurate, compact I/P, E/P, D/P & P/I electro-pneumatic transducers with extensive combinations of inputs and outputs carry standard FM, CSA, ATEX or IECEx agency approvals and maintain accuracies up to 0.15%. Fast response transducers, high flow transducers and high accuracy transducers developed by Fairchild feature proportional pressure regulation.
Industrial Process Transducers
The Process Control line of I/P Transducers utilizes a flapper and nozzle attached to a voice coil to proportionally regulate the output pressure. The Fairchild T5200, T5400, T5700 and T6000 pressure transducer series offer dependable performance at economical prices. The new T6100 I/P unit also offers "Lock in Last Place" reliability in an easy to use product configuration.
High Accuracy Electro-Pneumatic Transducers
The Fairchild T7800 series incorporates piezo ceramic disc actuation means while the T7900 and new T1750 series I/P pressure transducers use feed and bleed solenoid technology to provide a complete range of high performance transducers for every application. These electro-pneumatic I/P units are impervious to shock, vibration and positional orientation Explosion
Proof I/P Transducers
For applications with natural gas media and others which require reliable and accurate explosion proof I/P transducers, our TXPD6000 Voice Coil I/P, E/P Transducer and TXI7800 / TXI7850 Piezo Ceramic I/P Pressure Transducers carry all FM, CSA, ATEX and IECEx agency approvals for years to worry free operation. The TXI8750 incorporates patented technology to provide a moisture resistant I/P unit.
High Performance Electronic Transducers
Whether you demand high accuracy, high pressure, high flow, fast response or "all of the above," Fairchild has a complete line of high performance I/P, E/P Transducers to suit your application. From our 1000 psi "BIG BOSS™" T1750, to our 0.15% accuracy T7800 series, Fairchild I/P transducer models handle your toughest challenges.
Pneumatic Volume Boosters
Pneumatic volume boosters feature high flow capacity and fast response. A wide range of signal to output pressure ratios, pipe sizes and options are available in Fairchild's pilot operated regulator booster products with a Cv of 1 up to a Cv of 18, with flow capacities of 45 SCFM, 76.5 m3/hr up to 1500 SCFM, 2550 m3/hr.
Model 2000 - 40 SCFM [68 m3/Hr] Forward/Exhaust Flow No Bleed Volume Booster (M2000)
The Fairchild Model 2000 Pneumatic Volume Booster converts a low flow signal to a high flow output. It is ideally suited for a variety of applications including the operation of air systems that require rapid valve or cylinder action. As a pilot operated regulator design, the M2000 handles up to 250 psig, [17.0 BAR], (1700 kPa) supply pressure. The Fairchild Model 2000 provides a flow capacity of 40 SCFM (68 m3/HR), which results in a Cv factor of just less than 1.0 in forward flow mode.
Model 20 - 45 SCFM [76.5 m3/Hr] Forward/Exhaust Flow Volume Boosters (M20)
The Fairchild Model 20 Volume Booster is a smaller pneumatic device capable of high flow and exhaust capacity. This device uses a force balance system to control the movement of the supply and exhaust valves. As a pilot operated regulator design, the M20 handles up to 150 psig, [10.0 BAR], (1000 kPa) supply pressure and has ten available ratios to cover a wide range of applications. The Fairchild Model 20 Booster provides a flow capacity of 45 SCFM (76.5 m3/HR), which equates to a Cv factor of approximately 1.0 in both forward and exhaust modes.
M20 Back Pressure Pneumatic Booster (M20BP)
Fairchild's M20BP is a smaller Back Pressure Pneumatic Booster designed for automation or remote controlling of the back pressure or relief operation typically found in tank systems and other pressurized systems. In its pilot operated design, the
M20BP will operate from a signal pressure of up to 150 psig [10.0 BAR] (1000kPa) and handles up 250 psig, [17.0 BAR], (1700 kPa) system pressure. The Fairchild Model 20BP Back Pressure Booster provides a flow capacity of 45 SCFM (76.5 m3/HR), which equates to a Cv factor of approximately 1.0.
Model 4500 - 150 SCFM [255 m3/Hr] Forward/Exhaust High Flow No Bleed Volume Boosters (M4500A)
Fairchild's Model 4500 Pneumatic Volume Booster is popular due to its rugged design and high flow capacity in an economical package. In its pilot operated regulator design, the M4500 handles up 250 psig, [17.0 BAR], (1700 kPa) supply pressure and has five available signal to output ratios to meet most control element requirements. The Fairchild Model 4500 Booster provides a flow capacity of 150 SCFM (255 m3/HR), which equates to a Cv factor of approximately 3.0 in both forward and exhaust modes.
M4500A Back Pressure Pneumatic Booster (M4500ABP)
Fairchild’s M4500ABP is a High Flow Back Pressure Booster designed for automation or remote controlling of the back pressure or relief operation typically found in tank systems and other pressurized systems. In its pilot operated design, the M4500ABP will operate from a signal pressure of up to 150 psig [10.0 BAR] (1000kPa) and handles up 250 psig, [17.0 BAR], (1700 kPa) system pressure. The Fairchild Model 4500ABP Back Pressure Booster provides a flow capacity of 150 SCFM (255 m3/HR), which equates to a Cv factor of approximately 3.0.
Model 4800A - 500 SCFM [850 m3/HR] Forward/Exhaust High Flow No Bleed Volume Booster with Bypass Valve (M4800A)
Fairchild’s M4800A is a High Flow Pneumatic Volume Booster specifically designed for Valve and valve actuation systems. With its Cv of 9 in both forward and exhaust modes, this pilot operated booster provides fast response and accurate control for valve actuation. In addition, the M4800A has an integral bypass valve, for optimum tuning and adjustment, even while in operation, to obtain maximum performance on opening and closing times with minimal overshoot or oscillation. In its pilot operated regulator design, the M4800A handles up 250 psig, [17.0 BAR], (1700 kPa) supply pressure and delivers an output pressure up to 150 psig [10.0 BAR] (1000kPa). The Fairchild Model 4800A Booster provides a flow capacity of 500 SCFM (850 m3/HR), which equates to a Cv factor of approximately 9 in both forward and exhaust modes.
Model 4900A - 500 SCFM [850 m3/HR] Forward/Exhaust High Flow No Bleed Volume Booster (M4900A)
Fairchild’s M4900A is a High Flow Pneumatic Volume Booster designed for high precision applications. With its Cv of 9 in both forward and exhaust modes, this pilot operated booster provides fast response, very low deadband and high precision control. In its pilot operated regulator design, the M4900A handles up 250 psig, [17.0 BAR], (1700 kPa) supply pressure and delivers an output pressure up to 150 psig [10.0 BAR] (1000kPa). The Fairchild Model 4900A Booster provides a flow capacity of 500 SCFM (850 m3/HR), which equates to a Cv factor of approximately 9 in both forward and exhaust modes.
Model 200 - 1800 SCFM [3058 m3/Hr] Forward Ultra High Flow Volume Booster (M200)
The Model 200 Pneumatic Volume Booster reproduces a pneumatic signal in a 1:1 ratio. It is ideally suited for systems that require input isolation or increased forward flow capacity. This device uses a force balance system to control the movement of the supply and exhaust valves. As a pilot operated regulator design, the Fairchild Model 200 handles up to 250 psig, [17.0 BAR], (1700 kPa) supply pressure and provides a flow Ultra high flow capacity of 1800 SCFM (3058 m3/HR), which equates to a Cv factor of approximately 18 in forward flow mode.
Model 200XLR - 1800 SCFM [3058 m3/Hr] Forward/Exhaust Ultra High Flow Volume Boosters (M200XLR)
Based on the Model 200 valve body, the Model 200XLR Volume Booster couples two identical units to obtain ultra high flow capacity in both forward and exhaust modes. As a pilot operated regulator design, the Fairchild Model 200XLR handles up to 250 psig, [17.0 BAR], (1700 kPa) supply pressure and provides a flow Ultra high flow capacity of 1800 SCFM (3058 m3/HR), which equates to a Cv factor of approximately 18 in both forward and exhaust flow modes.
Our extensive line of pneumatic relays serves a multitude of control applications: positive biasing relays, positive and negative biasing relays, infinitely adjustable ratio relays, reversing relays, averaging and computing relays, high and low pressure selectors, and high and low pressure limiting relays.
Fairchild Biasing Relays
Positive and Negative Bias Relays are designed for applications that require an output pressure that is the sum of a controlled input signal plus or minus a fixed bias. Fairchild's line up of biasing pneumatic relay products includes both positive biasing relays, such as the Models 15, 85D and 1500A and relays that handle both positive and negative biasing functions such as the
Model 14. Reversing Relays
Reversing Relays are designed for applications requiring an output that equals a manually preset spring load minus a variable signal pressure. These high quality units, such as the Model 25 and Model 2500A, combine excellent sensitivity with unusually high flow capacity. These Fairchild reversing pneumatic relays are ideally suited for a variety of precision control applications, including converting direct acting valves to reverse action, controlling opposite acting valves from a single transmitter, and cushioning cylinder loads. Adjustable Ratio Relay
Fairchild's Model 21 is an Adjustable Ratio Pneumatic Relay, whereby the ratio of output pressure to signal pressure is infinitely adjustable. The adjustment range permits signal amplification of 1:30 or signal reduction of 30:1 by rotation of the ratio adjustment knob. The Model 21D is available with both input and output adjustable bias. Maximum input bias is 3 psig, with a maximum output bias of 9 psig.
Pneumatic Computing Relay
Designed for highly versatile control valve designed to perform a number of specialized functions, including averaging, differential, inverting, and totalizing, the Model 22 Pneumatic Computing Relay is a versatile Fairchild product. This high quality unit, which offers up to four inputs as well as positive and negative biasing over a broad range, is available in several configurations to meet most application requirements. Snap Acting Relay
The Model 24 Snap Acting Relay is a highly accurate differential relay with snap-acting switching. The output of the unit will go to supply pressure when the signal is equal to or greater than the setpoint. The signal pressure must fall below the set point to return the output to zero. This pneumatic relay's Near Zero Throttling and Pilot Staging result in true snap-action in your application. Selector Relays
The Model 90 Low Pressure and Model 91 High Pressure Selector Relays are designed to select the lower or higher of two signal pressures to provide a continuous output pressure to a control device. The Model 90 and 91 are recommended for dead end or low flow service in critical applications such as control loops requiring precise, automatic monitoring of signal pressures.
The entire product range is supported and offered quickly and reliably by Electroquip with on site stock held in Sittingbourne.
Call Electroquip to discuss your Fairchild Pneumatics requirements further.
